Steimel - PSF3/50RD-122458R
| Manufacturer | Steimel |
|---|---|
| Part Number | PSF3/50RD-122458R |
| Inner Code | 1877117 |
| Description | Gear Pump |
| Technical specification | P-SF3/50RD-VL, gear pump, 2-18 bar suitable for motor IEC 132, B5 or V1, noise-optimized Gear pump : SF 3/50 RD - VL Article no. : PSF3/50RD-122458R Dimension sheet : DPA053D-132LM-R31 Parts List : DET053050RD--165R Suction and pressure connection: SAE 1 1/2 Housing parts : EN-GJL-250 (GG-25) Pinion shafts, noise-optimized. : 16MnCrS5, egh., beveled Storage : Multilayer MD Shaft seal : Radial shaft seal Elastomers : FKM Pumping medium : lubricating oil Viscosity : 50-5000 cSt Temperature : 10-60°C Flow rate: approx. 70.8 l/min. Pressure : 5 bars Speed : 1450 rpm. pressure relief valve Opening pressure : 12 bar Setting range : 2-18 bar Direction of rotation : right Trial run : yes, with HLPD 46 Coupling : BKUA065-1938-301 Bellhousing : BLA053300150LA21 suitable for three-phase motor Size / design: IEC 132 / V 1 Coating : Primer HDO058 - green Nameplate : ETY924-D-E--PE01 Engine mounting screws : 4x IBO12X040VZ (zinc plated), loose screwed into pump carrier |
| Weight | 1 |
Please contact us to request a price quote for Steimel - PSF3/50RD-122458R, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PSF3/50RD-122458R by Steimel in United Kingdom?
You can purchase PSF3/50RD-122458R by Steimel from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PSF3/50RD-122458R?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Steimel in United Kingdom?
While we are not the official distributor or seller of Steimel in United Kingdom, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.
How can I access PSF3/50RD-122458R catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PSF3/50RD-122458R on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PSF3/50RD-122458R?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
