Steimel - ASF2-20RD-170046R
| Manufacturer | Steimel |
|---|---|
| Part Number | ASF2-20RD-170046R |
| Inner Code | 4524623 |
| Description | pump |
| Custom Code | 84136039 |
| Technical specification | A-SF2/20RD-VLFM, pump unit, 2-20 bar 1.5 kW, 1500, 230/400 V, 50 Hz, IP55, F, B5, IE3 1) 3 weeks length width height 623.00 210.00 240.00 millimetres millimetres millimetres Gear pump unit: SF 2/20 RD - VLFM Item no.: ASF2-20RD-170046R Dimension sheet: DPA052D-090LFM-R33 Spare parts list: DET052020RD-165R Suction and pressure connection: G 1/SAE 1 Housing parts: EN-GJL-250 (GG-25) Pinion shafts, noise opti.: 16MnCrS5, egh., helical gear Storage: multi-layer Shaft seal: radial shaft seal elastomers: FKM Pumping medium: lubricating oil Viscosity: 50-5000 cSt Temperature: 10-60°C Flow rate: 28.5/34.5 l/min. pressure: 5 bar Speed: 1450/1750 rpm. pressure relief valve Setting range: 2-20 bar Opening pressure: 8 bar Rotation direction: right Test run: yes, with HLPD 46 Coupling: BKUA040-1424-301 Bellhousing with foot: BLF052200110LA21 three-phase motor: LDM090-04-904 (Birkenbeul) Engine data: Power 1/2:1.5 /1.7 kW Speed 1/2:1500 /1800 rpm Voltage 1:230/400 volts at 50 Hz Voltage 2 265/460 volts at 60 Hz Efficiency class: IE3 Degree of protection: IP 55 Insulation class: F Design: B 5 with additional plate (without IE3) for: Voltage/frequency: 220-240/ 380-420 volts at 50/60 Hz 250-280/440-480 volts at 60 Hz Aggregate paint: primed Type plate: ETY924-D/E—PE02 |
| Weight | 35 |
Please contact us to request a price quote for Steimel - ASF2-20RD-170046R, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ASF2-20RD-170046R by Steimel in United Kingdom?
You can purchase ASF2-20RD-170046R by Steimel from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ASF2-20RD-170046R?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Steimel in United Kingdom?
While we are not the official distributor or seller of Steimel in United Kingdom, we source our products from reliable channels and offer you original Steimel equipment at competitive prices.
How can I access ASF2-20RD-170046R catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ASF2-20RD-170046R on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ASF2-20RD-170046R?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
