Stober - ED303USABR2O110
| Manufacturer | Stober |
|---|---|
| Part Number | ED303USABR2O110 |
| Inner Code | 1484754 |
| Description | Synchron-Servomotor |
| Custom Code | 85015100 |
| Technical specification | MV0000017959 Standstill current 1.14 A Rated current 1.10 A Stopping torque 1.41 Nm Engine torque 1.35 Nm Engine speed 3000 rpm Engine power 0.42 kW ED/EK type designation motor ED303USABR2O110 Cooling type convection cooled IC Output side IEC Quad 72 pass 60 lkr. 75 shaft version Ø 14x 30 without feather key Sprocket protection is eliminated Drive controller brand STOBER Encoder plug size/type special DC link voltage 540V DC link voltage Drive controller type/ connection MDS5000 Encoder type resolver Encoder type Resolver 2p GR15 standard Rated speed 3000 rpm 540V (KE= 110) ED Plug type special Mating plug without mating plug Special power connection Connection type location plug position 270° PTC thermal motor protection in the power connector Ambient temperature -15 to +40°C standard Thermal class (VDE 0530) 155 F Degree of protection (EN 60529) IP56 (EN 60529) Options Other1 cable ends 0.5m Kappelhof Operating mode of servomotors S1 Operating Painting 2 kg/2-comp. primer color RAL 9005 jet black Downforce painting options not painted Documentation language German Documentation language English |
| Weight | 2.8 |
Please contact us to request a price quote for Stober - ED303USABR2O110, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ED303USABR2O110 by Stober in United Kingdom?
You can purchase ED303USABR2O110 by Stober from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ED303USABR2O110?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Stober in United Kingdom?
While we are not the official distributor or seller of Stober in United Kingdom, we source our products from reliable channels and offer you original Stober equipment at competitive prices.
How can I access ED303USABR2O110 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ED303USABR2O110 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ED303USABR2O110?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
