TEKNIC - CPM-MCPV-2311S-RLN
| Manufacturer | TEKNIC |
|---|---|
| Part Number | CPM-MCPV-2311S-RLN |
| Inner Code | 4705800 |
| Description | Integrated Servo System |
| Technical specification | Motor Frame SizeNEMA 23 - 2.33 in (59.18 mm) sq. Length3.34 in (84.84 mm) Input (bus) Voltage Range24-75 VDC (90 VDC max) Peak Torque (@75 VDC)290 oz-in (2.0 N-m) Cont. (RMS) Torque (@75 VDC)58 oz-in (0.4 N-m) Max Speed (@75 VDC)4000 RPM Achievable Resolution0.450 degrees (0.057 deg. w/ Enhanced option) Repeatability0.03 degrees Shaft Diameter0.375 in (9.53 mm) Rotor Inertia0.4 oz-in² (0.1 kg-cm²) Logic Input Voltage Range4.0 to 28 VDC Maximum Radial Load25 lbf (111.2 N) Maximum Thrust Load5.0 lbf (22.2 N) Ambient Temperature1-40° to +70° C Ambient Humidity0-95%; non-condensing Environmental RatingDust & water splash resistant Regulatory CertificationsUL recognized; cUL recognized; CE; RoHS Safety2Supports STO (IEC 60204-1) Safety Requirements |
| Weight | 0.6 |
Please contact us to request a price quote for TEKNIC - CPM-MCPV-2311S-RLN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
