Telco - p/n: 11020, Type: SMR 3306 S30-5
| Manufacturer | Telco |
|---|---|
| Part Number | p/n: 11020, Type: SMR 3306 S30-5 |
| Inner Code | 1385804 |
| Description | Thru Beam Photoelectric Sensor |
| Technical specification | Operation Mode Thru Beam Function Receiver Supply Voltage 10 - 30 V dc Sensing Range 6 m Output PNP Output Status N.O. Housing Ø12,7 Snap Housing Material Plastic Connection 5 m cable Technical Data Supply Voltage 10 - 30 V dc Voltage Ripple 15 % Reverse Polarity Protected Yes Short Circuit Protected Yes Current Consumption Max. 8 mA Max. Output Load 100 mA Max. Residual Voltage 2,5 V Max. Operation Frequency > 90 Hz Response Time ton / toff < 4 ms / < 6 ms Output Indicator Yellow LED Hysteresis Approx. 25 % Opening Angle +/- 7° Housing Material, Front Lens Polycarbonate Housing Material, Sensor Housing Polycarbonate Cable 3 x 0,14 mm² Cable Sleeve PVC Ø 3,4 mm Environmental Data Vibration 10 - 55 Hz, 0,5 mm Shock 30 g Operation Temperature -20 to +50 °C Storage Temperature -40 to +80 °C Sealing Class IP 67 Light Immunity 5˚ 35 000 lux |
| Weight | 1 |
Please contact us to request a price quote for Telco - p/n: 11020, Type: SMR 3306 S30-5, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
