Thien E-Motoren - DKF 100LIB 334/8 / 110186
| Manufacturer | Thien E-Motoren |
|---|---|
| Part Number | DKF 100LIB 334/8 / 110186 |
| Inner Code | 5031356 |
| Description | Polar-switchable three-phase asynchronous motor |
| Custom Code | 85015220 |
| Technical specification | Polar-switchable three-phase asynchronous motor AS+NS with labyrinth seal AS bearing 6306/2RS-C3 (RS from Viton) NS bearing 6205/2RS-C3 K80/Ex terminal box RAL 7031 painting 010 engine type/version DKF 030 pin count 4/8 050 housing type aluminum 070-Technical version UL - without certificate 090 wave design AS standard 110 relubrication 130 gearbox 150 pulse generator 170 motor protection 190 output - 50Hz kW 210 current at 50Hz A 230 voltage - 60Hz 415 V 250 power - SO f. kW 275 circuit YY/ Y 290 operating mode S 1-100% ED 310 insulation class H 330 installation height m 020-frame size 100 040 design V1-250/180/215 060 terminal box position right 080 cooling self-ventilation 100-wave material Ck 45 = 1.1191 120-Condensate 140 brake type 160 backstop 180 standstill heater 200 voltage - 50Hz V 220 power - 60Hz 2.4/0.55 kW 240 current at 60Hz 5.4/2.2 A 270 current at SO f. A 280 speed 1730/850 rpm 300-Cos phi 0.81/0.60 320 protection class IP55 340 efficiency% |
| Weight | 26.5 |
Please contact us to request a price quote for Thien E-Motoren - DKF 100LIB 334/8 / 110186, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy DKF 100LIB 334/8 / 110186 by Thien E-Motoren in United Kingdom?
You can purchase DKF 100LIB 334/8 / 110186 by Thien E-Motoren from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the DKF 100LIB 334/8 / 110186?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Thien E-Motoren in United Kingdom?
While we are not the official distributor or seller of Thien E-Motoren in United Kingdom, we source our products from reliable channels and offer you original Thien E-Motoren equipment at competitive prices.
How can I access DKF 100LIB 334/8 / 110186 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for DKF 100LIB 334/8 / 110186 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for DKF 100LIB 334/8 / 110186?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
