TR Electronic - CEW582M-10199
| Manufacturer | TR Electronic |
|---|---|
| Part Number | CEW582M-10199 |
| Inner Code | 5010330 |
| Description | STRING ENCODER |
| Custom Code | 90318020 |
| Technical specification | CEW582M-10199 Pulley sensor CEW582M*8192/4096 EPN (OLD:CEW58M-00199) Total weight 1.150 kg Statistical product number: 90318020 Country of origin: GERMANY Region of origin: Baden-Württemberg AL:N ECCN:N Technical details appendix Order number description CEW582M-10199 CEW582M*8192/4096 EPN (OLD:CEW58M-00199) STEP COUNT 8,192,000 REVOLUTIONS 4,096,000 CONFIGURABLE VIA INTERFACE Profinet IO INTERFACE CODE BINARY SUPPLY VOLTAGE 10-30V PROTECTION CLASS IP65/SEE SLG WORKING TEMPERATURE -20°C... +75°C FLANGE TYPE DMS 2 WING DIVIDER 63 TORQUE SUPPORT (DMS) WAVE VARIANT CABLE LENGTH SENSOR (SLG) D12H7 SHAFT DESIGN Connection type 1x M12 04-PIN A-CODE MALE 2x M12 04-PIN D-CODE FEMALE AXIAL CONNECTION DIRECTION PIN ASSIGNMENT NUMBER TR-ECE-TI-DGB-0306 OPTION ENC REPLACEMENT FOR C_58 SLG ME-WDS-2000-P96-M-TRE SLG ITEM NUMBER 40730012 DRAWING NUMBER 04-CEW582M-M0021 AL: N ECCN: N mTTFd [y] (T=45°C, DC=0) >= 100 UL APPROVALS USA+CANADA SLG CABLE LENGTH 2000 mm SLG TRANSLATION 163.82... 164.22 mm/RPM SLG LINEARITY +/ -0.02% SLG SHAFT DESIGN 12GL/24 SLG HOUSING MATERIAL ALUMINUM SLG TEMPERATURE RANGE -20°C.. +80°C SLG PROTECTION CLASS IP54/IP65 OUTLET AT THE BOTTOM SLG SPRING FORCE min.5n/ max.11N SLG B10 VALUE 450,000 at 52,800 cycles p.a. SLG ROPE DIAMETER 0.8 mm SLG EXTENSION ANGLE max. +/-3° SLG CABLE ACCELERATION 8 g SLG PULLEY NO SLG SERVICE LIFE max. 10 years SLG ROPE POSITION RIGHT |
| Weight | 1.15 |
Please contact us to request a price quote for TR Electronic - CEW582M-10199, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
