Tri-Tronics - CMS-1BF1
| Manufacturer | Tri-Tronics |
|---|---|
| Part Number | CMS-1BF1 |
| Inner Code | 1879418 |
| Description | Sensor |
| Technical specification | COLORMARK™ II, 10ms Pulse Stretcher, Green LED, F1 Optical Block. 12-24 VDC polarity protected. Fiberoptic. Maximum Sensing Range is depending on fiber optics. Supply Voltage:12 to 24 VDC, Polarity Protected Current Requirements:85mA (exclusive of load) Output Transistors: (1) NPN and (1) PNP output transistor NPN: Sink up to 150mA PNP: Source up to 150mA Momentary short circuit protected Output transistors turn “ON” when mark is in view Anti-pulsing on power-up Response Time- Minimum duration of input event Light state response: 50 microseconds Dark state response: 140 microseconds Leading edge variation: less than 20 microseconds Hysteresis: Less than 400 millivolts for maximum sensitivity and resolution OFFSET/EDR® Clutch Knob Adjustment - Sets initial level on Contrast Indicator in relation to mid-scale switch point of 5 – functions as sensitivity adjustment. Controls Enhanced Dynamic Range circuit (EDR®) which functions to avoid glare effect LIGHT/DARK Switch: Dark position for dark mark; Light position for light mark Indicators: OUTPUT INDICATOR - Red LED illuminates when output transistors are “ON” EDR INDICATOR – Intensity of Green LED provides indication of where in the dynamic operating range the offset / EDR adjustment has been set FULLY LIT: Operating near saturation OFF: Operating near maximum sensing range CONTRAST INDICATOR –Displays returned contrasting light levels (background vs. mark) Light Immunity: Pulse modulated to provide extremely high immunity to ambient light Ambient Temperature: -40°C to 70°C (-40°F to158°F) Rugged Construction: Chemical resistant, high-impact polycarbonate housing Waterproof, ratings: NEMA 4X, 6P and IP67 Epoxy encapsulated for mechanical strength |
| Weight | 1 |
Please contact us to request a price quote for Tri-Tronics - CMS-1BF1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy CMS-1BF1 by Tri-Tronics in United Kingdom?
You can purchase CMS-1BF1 by Tri-Tronics from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the CMS-1BF1?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Tri-Tronics in United Kingdom?
While we are not the official distributor or seller of Tri-Tronics in United Kingdom, we source our products from reliable channels and offer you original Tri-Tronics equipment at competitive prices.
How can I access CMS-1BF1 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for CMS-1BF1 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for CMS-1BF1?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
