Turck - LI600P0-Q25LM0-ELIUPN8X3-H1151
| Manufacturer | Turck |
|---|---|
| Part Number | LI600P0-Q25LM0-ELIUPN8X3-H1151 |
| Inner Code | 765653 |
| Description | Inductive linear position sensor — IO-Link |
| Technical specification | ID:1590607 Measuring principle Inductive General data Measuring range 600 mm Resolution 0.009mm/16 bits Nominal distance 1.5 mm blind area a 29 mm blind zone b 29 mm Repeatability ≤ 36 µm Linearity deviation ≤ 0.04 % f.s. Temperature deviation ≤ ±0.003 % / K Hysteresis is not applied electrical data Operating voltage 15…30 VDC Stray surge ≤ 10 % Uss Insulation test voltage ≤ 0.5 kV Short circuit protection yes Wire break/Reverse polarity protection yes / Complete Communication protocol IO-Link Output function 5-pin, NO/NC contact, PNP/NPN analog exit Output 1 Switching output or IO-Link mode Output 2 Analog or switching output Voltage output 0…10 V Current output 4…20 mA programmable via IO-Link Load resistor voltage output ≥ 4.7 kΩ Load resistor current output ≤ 0.4 kΩ Sample rate 1000 Hz Current consumption < 50 mA IO-Link Features V 1.0 Parameterization FDT / DTM Process data width 16 bits Frame type 2.2 SIDI is included in GSDML Yes Mechanical data Design Profile, Q25L Dimensions 658 x 35 x 25 mm Housing material Aluminum/plastic, PA6-GF30, anodized Active site material plastic, PA6-GF30 Electrical connection Connectors, M12 × 1 Ambient conditions Ambient temperature -25…+70 °C Vibration resistance 55 Hz (1 mm) Impact resistance 30 g (11 ms) IP Rating IP67 Conforming to MTTF 138 year SN 29500 (Ed. 99) 40 °C Power-on indicator LED, green Measuring range display multifunctional LED, green, yellow, yellow blink |
| Weight | 1 |
Please contact us to request a price quote for Turck - LI600P0-Q25LM0-ELIUPN8X3-H1151, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy LI600P0-Q25LM0-ELIUPN8X3-H1151 by Turck in United Kingdom?
You can purchase LI600P0-Q25LM0-ELIUPN8X3-H1151 by Turck from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the LI600P0-Q25LM0-ELIUPN8X3-H1151?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Turck in United Kingdom?
While we are not the official distributor or seller of Turck in United Kingdom, we source our products from reliable channels and offer you original Turck equipment at competitive prices.
How can I access LI600P0-Q25LM0-ELIUPN8X3-H1151 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for LI600P0-Q25LM0-ELIUPN8X3-H1151 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for LI600P0-Q25LM0-ELIUPN8X3-H1151?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
