Turck - PGCA-1A
| Manufacturer | Turck |
|---|---|
| Part Number | PGCA-1A |
| Inner Code | 762710 |
| Description | Control box |
| Technical specification | Width of defined area: 6 inches (15 cm) minimum, 3x excess gain at 45 feet (14 meters); somewhat less when lens shields or corner mirrors are used Minimum object sensitivity: 1.5 inches (38,1 mm); assumes no floating blanking in use. Response time: Less than 40 milliseconds when used with an emitter and receiver up to and including 4 feet in length; less than 55 milliseconds when used with an emitter and receiver of 54 to 72 inches in length. Self-checking interval: 20 milliseconds Ambient light immunity: >10,000 lux at 5° angle of incidence Strobe light immunity: Totally immune to one Federal Signal Corp. "Fireball" model FB2PST strobe. Emitter elements: Infrared LEDs; 880nm peak emission System power requirements: Control box PGCA-1A: 115V ac (50/60Hz), 50 VA Fuse rating: Control box PGCA-1A: 1/2 amp, 250V ac (3AG slow blow) Diagnostic indicators: Four LEDs indicate 7 system status conditions Controls and adjustments: Keyed RESET of system lockout conditions ARRAY SIZE selection switches BLANKING function selection switches AUTO POWER-UP selection switches Alarm relay: Reed relay; 125V ac or dc max., 500 mA. max. (10VA maximum, resistive load) Output configuration (FSD1, FSD2, and SSD): Forced-guided contact relays, 250V ac max., 4 amps max. (resistive load). Mechanical life 10,000,000 operations (minimum). Electrical life (at full rated load) 100,000 operations (typical). Arc suppression is recommended when switching inductive loads. See Figure 15, page 19. Operating temperature: 0 to +50°C (+32 to 122°F) Relative humidity: 95% maximum (non-condensing) |
| Weight | 1 |
Please contact us to request a price quote for Turck - PGCA-1A, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
