Turck - RI-42H30S4-2B1024-12M23
| Manufacturer | Turck |
|---|---|
| Part Number | RI-42H30S4-2B1024-12M23 |
| Inner Code | 765735 |
| Description | encoder |
| Technical specification | İdent no. 1545228 Measuring principle Photoelectric Max. Rotation Speed 3000 U/min Rotor Moment of Inertia 150x10-6 kgm2 Starting torque 0.2 Nm Ambient temperature -40…+70 °C Operating speed 10…30 VDC No load current I0 ð 100 mA Output current ð 30 mA short circuit protection yes Output type Ascending Resolution, incremental 1024 ppr Impact compression max. 300kHz Signal level high min. UB - 3V Signal level low max. 2.5 volts Design Hollow love Flange type Mounted flash Flange diameter 100 mm Shaft type Hollow shaft Shaft diameter D [mm] 30 mm Shaft Stainless material steel Body Die-cast material frame Electrical connection Connectors, M23 radial Vibration resistance (EN 60068-2-6) 100 m/s², 10…2000 Hz Impact strength (EN 60068-2-27) 1000 m/s², 6 ms Protection class enclosure IP65 Transmitters with protection class IP65 Shipment package content Spring element, long |
| Weight | 1 |
Please contact us to request a price quote for Turck - RI-42H30S4-2B1024-12M23, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
