Turck - WIM160-Q25L-LI-EXI-H1141
| Manufacturer | Turck |
|---|---|
| Part Number | WIM160-Q25L-LI-EXI-H1141 |
| Inner Code | 766602 |
| Description | Magnetic driven angle sensors |
| Technical specification | ID 1536644 Measuring principle Magnetic General data Measuring range 160 mm Resolution 0.16 mm/10 bit Repeatability ≤ 0.1% of measuring range IA - BI depending on positioning element Linearity deviation ≤ 1 % Temperature drift ≤ ± 0.03 % / K Electrical data Operating voltage 14…30 VDC Residual ripple ≤ 10 % Uss Isolation test voltage ≤ 0.5 kV Short-circuit protection yes Wire breakage/Reverse polarity protection yes / Complete Output function 4-pin, Analog output Current output 4…20 mA Load resistance current output ≤ [(UB -14 V) / 20 mA] kΩ Sample rate 200 Hz Approval acc. to KEMA 03 ATEX 1122 X Issue no. 2 Internal capacitance (Ci)/inductance (Li) 0 nF/0 µH Device marking É II 2 G Ex ia IIC T6 Gb / II 2 D Ex ia IIIC T85 °C Db (max. Ui = 30V, Ii = 120mA, Pi = 675mW) Mechanical data Design Profile, Q25L Dimensions 201 x 35 x 25 mm Housing material Aluminum/plastic, PA6-GF30 Active area material Plastic, PA6-GF30 Electrical connection Connector, M12 × 1 Environmental conditions Ambient temperature -25…+65 °C For explosion hazardous areas see instruction leaflet Vibration resistance 55 Hz (1 mm) Shock resistance 30 g (11 ms) Protection class IP67 MTTF 131 years |
| Weight | 1 |
Please contact us to request a price quote for Turck - WIM160-Q25L-LI-EXI-H1141, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy WIM160-Q25L-LI-EXI-H1141 by Turck in United Kingdom?
You can purchase WIM160-Q25L-LI-EXI-H1141 by Turck from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the WIM160-Q25L-LI-EXI-H1141?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Turck in United Kingdom?
While we are not the official distributor or seller of Turck in United Kingdom, we source our products from reliable channels and offer you original Turck equipment at competitive prices.
How can I access WIM160-Q25L-LI-EXI-H1141 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for WIM160-Q25L-LI-EXI-H1141 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for WIM160-Q25L-LI-EXI-H1141?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
