United Electric Controls - 1XSWLL-P15-M201-QC1
| Manufacturer | United Electric Controls |
|---|---|
| Part Number | 1XSWLL-P15-M201-QC1 |
| Inner Code | 4838201 |
| Description | Pressure switch |
| Technical specification | Gauge Pressure – 316L stainless steel wetted parts, welded diaphragm, 1/2” NPT (female) process connection, micro-machined piezo-resistive strain gage silicon element, 0.25 ml silicone oil fill, maximum diaphragm displacement: 0.00053 inches Maximum media temperature: -40 to 257°F (-40 to 125°C) P15: Pressure Operating Range: 0-300.0 psig / 0-20,68 bar Maximum Over Range: 600 psig / 41,4 bar Power input/Switch capacity: Maximum Power Ratings / Output Signal: 2-wire 7.8 – 50 VDC discrete input powered @ 0.75 mA Set Point Switch Ratings (SPST): 7.8 – 50 VDC @ 0.1 A IAW Switch Ratings: 7.8 – 50 VDC @ 0.1 A Accuracy: 0.5% of full range span, at room temperature Approved ambient operating temperature range: -40°F to 185°F (-40°C to 85°C) Enclosure and cover: Type 4X/IP66 certified epoxy-coated aluminum alloy 360 with tempered glass window. Electrical Conduit: 3/4” NPT female aluminum casting; 2 openings Set point & deadband: Programmable over the sensor's entire range Options: M201: Factory set one switch / Please provide pressure value(s), deadband and rising, falling or window mode! QC1: Certificate of Conformance / Calibration Certificate |
| Weight | 2.7 |
Please contact us to request a price quote for United Electric Controls - 1XSWLL-P15-M201-QC1, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
