Wenglor - MLWL131
| Manufacturer | Wenglor |
|---|---|
| Part Number | MLWL131 |
| Inner Code | 4075826 |
| Description | 2D/3D Profile Sensor |
| Custom Code | 90318020 |
| Technical specification | Optical Data Working range Z 70 ... 130 mm Measuring range Z 60 mm Measuring range X 30 ... 52 mm Linearity Deviation 15 µm Resolution Z 2 ... 4.9 µm Resolution X 17 ... 26 µm Light Source Laser (blue) Wavelength 405 nm Service Life (T = +25 °C) 20,000 h Laser Class (EN 60825-1) 2 Environmental conditions Ambient temperature 0 ... 45 °C Storage temperature -20 ... 70 °C Max. Ambient Light 5,000 Lux EMC DIN EN 61000-6-2; 61000-6-4 Shock resistance per DIN IEC 68-2-27 30 g / 11 ms Vibration resistance per DIN IEC 60068-2-6 6 g (10...55 Hz) Atmospheric humidity 5...95%, non-condensing Electrical Data Supply Voltage 18 ... 30 V DC Current Consumption (Ub = 24 V) 330 mA Measuring Rate 175 ... 6,000 /s Subsampling 350 ... 6,000 /s Inputs/Outputs 4 Switching Output Voltage Drop < 1.5 V Switching Output/Switching Current 100 mA Short Circuit Protection yes Reverse Polarity Protection yes Overload Protection yes Interface Ethernet TCP/IP Baud Rate 100/1000 Mbit/s Protection Class III FDA Accession Number 1710273-000 Mechanical Data Housing Material Aluminum, anodised Degree of Protection IP67 Connection M12 × 1; 12-pin Type of Connection Ethernet M12 × 1; 8-pin, X-cod. Optic Cover Glass |
| Weight | 0.623 |
Please contact us to request a price quote for Wenglor - MLWL131, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy MLWL131 by Wenglor in United Kingdom?
You can purchase MLWL131 by Wenglor from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the MLWL131?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Wenglor in United Kingdom?
While we are not the official distributor or seller of Wenglor in United Kingdom, we source our products from reliable channels and offer you original Wenglor equipment at competitive prices.
How can I access MLWL131 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for MLWL131 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for MLWL131?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
