Wöhner - 32168
| Manufacturer | Wöhner |
|---|---|
| Part Number | 32168 |
| Inner Code | 1804823 |
| Description | Universal Busbar Adapter |
| Technical specification | - 250 A, with box terminals 95mm² - outlet at the top, - Width: 110mm, length: 320mm Information IEC standards IEC 61439- 1:2011 GB/T 7251.1 Electrical values IEC Rated current (IEC): 250 A Rated voltage (IEC) AC: 690 V Rated insulation voltage Ui AC: 800 V Rated surge voltage Uimp: 6 kV Dissipation of the item: With a practical load of 80%, the power output is 22.2 W. (At full load, the power output is 34.6 W.) additional data IEC The following values are demonstrated by tests under certain conditions. For the specific planning of the plant, the respective conditions must be inquire with Wöhner. Max. permissible voltage (IEC) DC: 800 V Rated surge current resistance Ipk max.: 55.8 kA Information UL standards UL 508 Electrical values UL Rated current (UL): 250 A Rated voltage (UL) AC: 600 V Mechanical values W x H x D: 110 x 320 x 101 Weight: 160.4 kg/100 Polarity: 3-pin For busbars: 12, 15, 20, 25, 30 x 5, 10 and mounting angles Material properties Casing: temperature resistant up to 125°C, self-extinguishing according to UL 94, leakage resistance CTI 600, halogen-free |
| Weight | 1.604 |
Please contact us to request a price quote for Wöhner - 32168, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
