Fristam - FSP 3532/175 VB

Manufacturer Fristam
Part Number FSP 3532/175 VB
Inner Code 5153858
Custom Code 84798200
Technical specification

FSP 3532/175 VB shear pump
pump with motor base
Pump material: 1.4404 (316L)
Shaft sealing: 9.667A (2K10V2/2N5V2)
1. Tungsten carbide/FKM
2. coal/chrome casting/FKM
Elastomers: FKM with FDA certification
Connection type: SMS thread
Suction side: 3"
Pressure page: 3"
Wheel diameter: 175 mm
Engine: 18.5 kW, n = 2900 rpm

50 Hz, ISO class: F
Voltage 400/690V
IP 65
ATEX outside the pump:
- Pump suitable for: II2D Ex h IIIB T135°C Db/ Zone 21
- Pump unit suitable for: II2D IIIB T135°C Db/ Zone 21
ATEX note:
The instructions in the operating instructions of the devices, order-related
Documents and ATEX additional operating instructions must be complied with.
Valid laws and guidelines for operating devices in a
It is essential to maintain an explosive atmosphere.
The operator of the pump must ensure that during operation at all times
Product or barrier medium is pending on the shaft seal!
Funding dates:
product = -
8 - 20 m³/h versus 25 m Fls
Temperature = 20 - 85°C
Viscosity = 200 mPa*s --- Density = 1.2 kg/l
Certificates/Exams:
Documentation exclusively in accordance with Fristam standards, unless otherwise
confirmed.
- FDA certification/EC1935/2004
Generally:
- special paint RAL 9007/gray aluminum
engine:
- IEC160L engine size
- Terminal box location: above
- with cold conductor temperature sensor
- according to efficiency class IE3
- with Ex protection in accordance with II 2 D Ex tb IIIB T135C° Db/ Zone 21 - in accordance with ATEX
Shear pump:
- Combination: 21a Ø114/21a
- Adjustment size Z: 24.5mm
Shaft sealing:
- GLRD: double-acting
Rinsing water pressure max. 0.2 bar
incl. flush water connection with G1/8" pipe
other agreements:
Shearpump similar to serial number 0574 71 0006 but without counterparts
Prepared for operation with a frequency converter. speed range 1.450 -
2,900 rpm (25 - 50 Hz)
Weight 145
