Orbinox - ORBINOX-Knife Gate Typ EXN
| Manufacturer | Orbinox |
|---|---|
| Part Number | ORBINOX-Knife Gate Typ EXN |
| Inner Code | 3371335 |
| Technical specification | Wafer gate valve in short length, sealing on one side, for installation between flanges according to EN 1092-2 PN 10 Nominal size: DN200 Housing: GJL 250 / GG 25, epoxy-coated RAL 5015 Knife: stainless steel AISI 304 (1.4301) Piston rod: stainless steel AISI 430 (1.4016) Mounting bracket: steel, epoxy-coated Contact protection: stainless steel AISI 304 (1.4301) Stuffing box gland: up to DN 300 aluminum, from DN 350 ductile cast iron Stuffing box packing: PTFE-impregnated synthetic fiber (type ST) with EPDM O-ring Sealing ring: EPDM Sealing clamping ring: Type A (standard), stainless steel AISI 304 (1.4301) Actuation: double-acting pneumatic actuator made of aluminum Control pressure: 5 - 7 bar permissible differential pressure in flow direction: DN 50 to 250 = 10 bar, DN 300 to DN 400 = 6 bar DN 450 = 5 bar, DN 500 to DN 600 = 4 bar |
| Weight | 34 |
Please contact us to request a price quote for Orbinox - ORBINOX-Knife Gate Typ EXN, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy ORBINOX-Knife Gate Typ EXN by Orbinox in United Kingdom?
You can purchase ORBINOX-Knife Gate Typ EXN by Orbinox from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the ORBINOX-Knife Gate Typ EXN?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Orbinox in United Kingdom?
While we are not the official distributor or seller of Orbinox in United Kingdom, we source our products from reliable channels and offer you original Orbinox equipment at competitive prices.
How can I access ORBINOX-Knife Gate Typ EXN catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for ORBINOX-Knife Gate Typ EXN on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for ORBINOX-Knife Gate Typ EXN?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
