Planetroll - (0,047D2)MRV(P11-7,667-0(11k6x23))
| Manufacturer | Planetroll |
|---|---|
| Part Number | (0,047D2)MRV(P11-7,667-0(11k6x23)) |
| Inner Code | 3808856 |
| Description | planetroll control reducer |
| Custom Code | 85015100 |
| Technical specification | 602-08042 consisting of: a) Three-phase motor b) Standard gear “p l a r o m a s t e r” c) Planetary gear Dimension sheet: M070 802 specifications — Mounting side: right Design: B14 Installation position: 4 Speed range: 0 to approx. 145/174 1/min (50/60 Hz) Output torques: approx. 4.5 Nm from 7.8/9.4 to 26 rpm approx. 1.5/1.2 Nm at 145/174 rpm Drive Components: 1 501-01220 1 PC drive three-phase motor, 0.044/0,046 kW, 2600/3100 rpm, 230/400 V, 50/60 Hz, 0.27/0.16 A IP 40, Isol.Kl.E, flange B14-62, centering collar diam. 26, shaft 9 x 25 mm. 2 302-00008 1 PCS Varial-speed gearbox plaromaster type MRV drive side: Drive hollow shaft Ø9 with clamping element; centering Ø25, 4x Ø4.5 on TK36 output side: for mounting on planetary gearboxes type P11 3 302-00002 1 PCS Control element type: HVN, coarse scale 0-12, fine scale 0-100 4 301-00962 1 PCS output side planetary gearbox type P11-0, reduction ratio i = 7.667, 4x Bo.M4 on TC dia.47 Output shaft dia.11k6 x 23, (max.persive.output torque M2=4.5 Nm). |
| Weight | 3.4 |
