Planetroll - 0,067D2MRVP11-7,667-0(11k6x23)
| Manufacturer | Planetroll |
|---|---|
| Part Number | 0,067D2MRVP11-7,667-0(11k6x23) |
| Inner Code | 3304290 |
| Description | Variable speed drive unit |
| Custom Code | 85015100 |
| Technical specification | 602-07690 consisting of: 1) Three-phase motor 2) Automatic transmission “p l a r o m a s t e r” 3) Control element 4) Planetary gearbox 5) Varnishing specifications Control element: right Design: B14-like Installation position: 4 Speed range: 0 to approx. 143/172 rpm (50/60 Hz network) Output torques: max. 4.5 Nm from 2.6/3.1 to 94 rpm approx. 3.1/2.6 Nm at 143/172 rpm 1 1 PC drive-side three-phase motor 0.066/0.072 kW, 2600/3100 rpm, 230/400 V, 50/60 Hz, 0.48/0.26 A, IP 54, Isol.Kl.F, flange B14-62, centering band diameter 32, shaft 9x25, plastic bushing on Terminal box, fan cover black (unpainted). 302-000142 1 PC plaromaster type MRV variable speed transmission Drive side: for motor mounting: flange B14-62, centring band diameter 32, shaft 9x25. output side: for mounting P11 planetary gearboxes 302-000023 1 PC Control element type: HVN, rough scale 0-12, fine scale 0-100 301-009624 1 PC output-side planetary gearbox type P11-0, reduction i = 7.667, 4x Bo.M4 on TK diameter 47, Output shaft diameter 11k6 x 23, (max. output torque M2=4.5 Nm). 602-088795 1 PC + RAL 9006 painting -white aluminum- |
| Weight | 3.5 |
Please contact us to request a price quote for Planetroll - 0,067D2MRVP11-7,667-0(11k6x23), or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
