PN: SK 3238.124 Rittal Sales In United Kingdom
| Manufacturer | Rittal |
|---|---|
| Part Number | PN: SK 3238.124 |
| Inner Code | 3367150 |
| Description | TopTherm filter fans |
| Custom Code | 84145915 |
| Technical specification | Article number: SK 3238.124 execution wall mounting product description Filter fans with diagonal fan technology are more pressure-stable and offer a more constant air output. The diagonal outflow direction ensures more even heat dissipation of the control cabinet. Color RAL 7035 scope of delivery Completely ready-to-install unit, including fleece filter mat fan Axial, DC motor air performance free blowing (with fleece filter) At DC: 52 m³/h air performance free blowing (with pleated filter) At DC: 63 m³/h Air output with outlet filter including fleece filter mat (number x order number) 1 x 3238200: 36 m³/h 2 x 3238200: 46 m³/h rated operating voltage 24 V (DC) rated power Pel At DC: 5.7 W Rated current max. At DC: 0.24 A dimension Width: 148.5 mm Height: 148.5 mm installation depth 58.5 mm mounting cutout Cutout width: 124 mm Cutout height: 124 mm Protection class IP according to IEC 60 529 IP54 with fleece filter/pleated filter IP56 with fleece filter/pleated filter and jet water hood protection class NEMA Type 12 with fleece filter/pleated filter Type 3 Type 3R Type 4 Type 4X with fleece filter/pleated filter and jet water hood backup fuse Circuit breaker/fuse: 2 A Notice To increase the air output, a pleated filter can be used optionally (see characteristic curve). This can be used with both the filter and roof ventilators and the outlet filters. For the filter fan 3237.XXX, the electrical connection is made via 2 single wires (length approx. 300 mm) on the device, for all other filter fans via spring terminal operating temperature range -15 °C...55 °C storage temperature range -30 °C...70 °C sound pressure level At DC: 46 dB(A) Weight/unit 0.54 kg packaging unit 1 piece net weight 0.539 kg gross weight 0.64 kg customs tariff number 84145915 EAN 4028177651722 ETIM 9 EC000320 ETIM 8 EC000320 ECLASS 8.0 27180716 product description SK filter fan TopTherm, 52 m³/h, 24 V (DC), WHT: 148.5 x 148.5 x 16 mm |
| Weight | 0.539 |
Please contact us to request a price quote for Rittal - PN: SK 3238.124, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy PN: SK 3238.124 by Rittal in United Kingdom?
You can purchase PN: SK 3238.124 by Rittal from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the PN: SK 3238.124?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Rittal in United Kingdom?
While we are not the official distributor or seller of Rittal in United Kingdom, we source our products from reliable channels and offer you original Rittal equipment at competitive prices.
How can I access PN: SK 3238.124 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for PN: SK 3238.124 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for PN: SK 3238.124?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
