RTK Regeltechnik - MV 5324, DN 125, PN 16

Manufacturer RTK Regeltechnik
Part Number MV 5324, DN 125, PN 16
Inner Code 5135486
Technical specification

Motor control valve - MV 5324 series
in three-way form for mixing
nominal size DN 125, nominal pressure PN 16
Housing material ductile iron EN-GJS-400-18-LT
Flanges with DIN sealing surface
Spindle sealing:
Bellows with PTFE safety plug
Characteristic/flow rate: linear/-
mixing cone, metallic sealing
Kvs value = 231 m³/h, stroke 35 mm
Seat diameter 125 mm
Surface treatment with zinc dust primer
CE marking in accordance with Pressure Equipment Directive (PED)
max. allowable pressure in accordance with DIN EN 1092
max. allowable temperature TS 350 °C

Electrical actuator - type ReAct 100E-045
Positioning force 10 kN, including manual adjustment
230 V 50/60 Hz AC motor
Adjustment speed 0.45 mm/s, stroke 35 mm
Protection class IP 65
- additional limit switches (2 pieces)
Weight 80

Please contact us to request a price quote for RTK Regeltechnik - MV 5324, DN 125, PN 16, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.


WE SELL ONLY NEW AND ORIGINAL PRODUCTS!

Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.

Where can I buy MV 5324, DN 125, PN 16 by RTK Regeltechnik in United Kingdom?

You can purchase MV 5324, DN 125, PN 16 by RTK Regeltechnik from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.

What is the price of the MV 5324, DN 125, PN 16?

For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.

Who is the official distributor or seller of RTK Regeltechnik in United Kingdom?

While we are not the official distributor or seller of RTK Regeltechnik in United Kingdom, we source our products from reliable channels and offer you original RTK Regeltechnik equipment at competitive prices.

How can I access MV 5324, DN 125, PN 16 catalogs, user manuals, technical documents, and PDFs?

You can access catalogs, user manuals, and technical documents for MV 5324, DN 125, PN 16 on our website. Visit our resources section or contact us directly for specific documents.

Do you provide technical support for MV 5324, DN 125, PN 16?

While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
