Scherzinger - 5030-210-B-ZK-90-160
| Manufacturer | Scherzinger |
|---|---|
| Part Number | 5030-210-B-ZK-90-160 |
| Inner Code | 4513574 |
| Description | Threaded Flange Pump |
| Custom Code | 84136039 |
| Technical specification | 204652 specifications •Explosion protection: 2014/34/EU - II 2G Ex h IIC Gb X//II 2D Ex h IIC Db X Preferred direction of rotation: left (CCW), look at the pump shaft Displacement volume: 21 cm³/rpm Safety valve: 0 - 12 bar Connections: DIN ISO 228, G 1" Perm. Pump inlet pressure: -0.9... 49 bar Operating temperature range: -20 to 130°C construction materials • • • • • • Housing material: 1.4404 Gear material: PEEK mod. Waves: 1.4571 Plain bearings: PEEK mod. stat. Seals: PTFE Shaft seal: • Max.14 Nm • Sm2Co17 magnets, encapsulated in 1.4404 for mounting on a standard motor • • • • • • • • with motor-side magnetic coupling bell Engine standard: IEC 72-1 Size: IEC90S Construction type: IMB34 flange diameter: 160 mm shaft: 24x50 mm recommended power: 1.1 kW recommended speed: 1,500 rpm Important notes Please install a coarse filter with a mesh size of 50 µm in front of the pump Pump not suitable for liquids with magnetic particles Pump not suitable for particle-laden media According to ISO 4406, the purity class of the medium should be at least 19/17/14 |
| Weight | 20 |
Please contact us to request a price quote for Scherzinger - 5030-210-B-ZK-90-160, or for any other model as well. We offer competitive prices, fast delivery and a wide products distribution network in the UK.
WE SELL ONLY NEW AND ORIGINAL PRODUCTS!
Our company is not an authorized distributor. All rights are reserved by the manufacturers and their official partners.
Where can I buy 5030-210-B-ZK-90-160 by Scherzinger in United Kingdom?
You can purchase 5030-210-B-ZK-90-160 by Scherzinger from RADWARD LTD. We serve customers across United Kingdom, offering competitive prices and reliable service.
What is the price of the 5030-210-B-ZK-90-160?
For customized pricing and availability, please fill out our contact form or give us a call. We are dedicated to providing solutions that align with your specific requirements.
Who is the official distributor or seller of Scherzinger in United Kingdom?
While we are not the official distributor or seller of Scherzinger in United Kingdom, we source our products from reliable channels and offer you original Scherzinger equipment at competitive prices.
How can I access 5030-210-B-ZK-90-160 catalogs, user manuals, technical documents, and PDFs?
You can access catalogs, user manuals, and technical documents for 5030-210-B-ZK-90-160 on our website. Visit our resources section or contact us directly for specific documents.
Do you provide technical support for 5030-210-B-ZK-90-160?
While we do not offer direct technical support, we can assist you in contacting the manufacturer to ensure you receive the support you need.
